Meet the new Haley Sportster S

Sportster S is the first chapter of a whole new book of the Sportster saga. A model born in 1957 that outperformed the competition is now rebuilt to sports performance, fuelled by a 121-hp version of the liquid-cooled Revolution Max V-Twin and a host of modern electronics. The price starts from $14,999 MSRP

Feature Highlights:

ENGINE

•Type: Revolution Max 1250T 60-degree V-twin
•Displacement: 1252cc
•Bore x stroke: 105 x 72.3mm
•Maximum power: 121 horsepower @ 7500 rpm
•Maximum torque: 94 ft-lbs @ 6000 rpm
•Compression ratio: 12.0:1
•Valvetrain: DOHC w/ hydraulic self-adjusting lifters, variable intake and exhaust timing; 4vpc
•Cooling: Liquid
•Lubrication: Semi-dry sump
•Exhaust: 2-1-2 w/ in-muffler catalyst
•Transmission: 6-speed
•Clutch: Wet multiplate w/ assist and slipper functions
•Final drive: Chain

CHASSIS

•Frame: Alloy steel trellis w/ forged aluminum mid-structure
•Front suspension; travel: Fully adjustable 43mm inverted fork; 3.6 inches
•Rear suspension; travel: Linkage-assisted fully adjustable shock; 2 inches
•Wheels: Cast aluminum
•Front wheel: 17 x 4.5
•Rear wheel: 16 x 5
•Tires: Dunlop Harley-Davidson Series GT503
•Front tire: 160/70 x 17
•Rear tire: 180/70 x 16
•Front brakes: 320mm floating disc w/ radially mounted 4-piston Brembo caliper
•Rear brake: 260mm disc w/ single-piston Brembo floating caliper
•ABS: Cornering aware

DIMENSIONS and CAPACITIES

•Wheelbase: 59.8 inches
•Rake: 30 degrees
•Fork angle: 28 degrees
•Trail: 5.8 inches
•Seat height: 29.6 inches
•Fuel capacity: 3.1 gallons
•Estimated fuel consumption: 49 mpg
•Curb weight: 502 pounds

COLORS

•Vivid Black
•Stone Washed White Pearl (+$350)
•Midnight Crimson (+$350)
