BMW S1000RR Specifications - Engine, Power, Dimensions & Performance
Full technical specs for BMW S1000RR: engine details, horsepower, torque, weight, top speed, and more. Check official specifications and performance data on Moto Riders Universe.
Years
Generations
HP4 (K42) (2013–2015)
Engine
- Engine Type
- Inline 4
- Number of Cylinders
- 4
- Engine Stroke
- 4-stroke
- Valves
- 16
- Valves Per Cylinder
- 4
- Valve Configuration
- DOHC
- Cooling System
- Liquid-cooled
- Engine Oil
- 5W-40
- Lubrication
- Wet Sump
- Induction
- EFI
- Spark Plug
- NGK LMAR9D-J
- Starting
- Electric
- Gear Ratio per Gear
-
1st - 2.647
2nd - 2.091
3rd - 1.727
4th - 1.500
5th - 1.360
6th - 1.261
- Displacement
- 999 cc
- Bore X Stroke
- 80 × 49.7 mm
- Compression Ratio
- 13.0:1
- Horsepower
- 193 hp (144 kW) / 13,000 rpm
- Torque
- 112 Nm / 9,750 rpm
- Fuel System
- Injection
- Fuel Type
- Petrol
Transmission
- Transmission Type
- Manual
- Number Of Speeds
- 6-speed
- Clutch
- Wet Multi-Plate
- Primary Drive Ratio
- 1:1.652
- Final Drive Ratio
- Chain, 17/45
- Reverse
- No
Chassis
- Frame
- Bridge-type aluminium, load-bearing engine
- Rake (fork angle)
- 24.0°
- Trail
- 99 mm / 3.90 in
- Front Suspension Type
- USD fork, DEC (Dynamic Damping Control), 46 mm
- Front Wheel Travel
- 120 mm / 4.72 in
- Rear Suspension Type
- Aluminium double-sided swingarm with DDC central spring strut
- Rear Wheel Travel
- 130 mm / 5.12 in
Dimension
- Overall Length
- 2056 mm / 80.94 in
- Overall Width
- 826 mm / 32.52 in
- Seat Height
- 820 mm / 32.28 in
- Seat Type
- Split
- Wheelbase
- 1422 mm / 55.98 in
- Ground Clearance
- 133 mm / 5.24 in
- Dry Weight
- 169 kg / 372.58 lb
- Wet Weight
- 199 kg / 438.72 lb
- Fuel Capacity
- 17.5 l / 4.62 gal
- Overall Heigth
- 1138 mm / 44.80 in
Brakes and tyres
- Front Brake Type
- Dual Disc
- Rear Brake Type
- Single Disc
- Front Brake Diameter
- 320 mm / 12.60 in
- Rear Brake Diameter
- 220 mm / 8.66 in
- Tube / Tubeless
- Tubeless
- Wheel Type
- Alloy
- Front Wheel
- 17"
- Rear Wheel
- 17"
- Front Tire Size
- 120/70 ZR17
- Rear Tire Size
- 200/55 ZR17
Instrument console features
- Speedometer
- Digital
- Tachometer
- Digital
- Fuel Gauge
- Digital
Battery and lighting
- Pass Light
- Yes
- Battery Type
- Maintenance-free
- Battery Voltage
- 12 V / 7 Ah
- Headlight Type
- Dual projector (halogen)
- Turn Signals Type
- LED
Comfort features
- Electric Start
- Yes
- Pillion Footrest
- Yes
- Step-up Seat / Split Seat
- Yes
- ABS available
- Yes
- Top Speed
- 300 km/h / 186 mph
Colors
Racing Blue Metallic / Light White
