Kawasaki Ninja H2/H2R Specifications - Engine, Power, Dimensions & Performance
Full technical specs for Kawasaki Ninja H2/H2R: engine details, horsepower, torque, weight, top speed, and more. Check official specifications and performance data on Moto Riders Universe.
Years
Generations
Ninja H2 (Gen 1) (2015–2018)
Engine
- Engine Type
- Inline 4
- Number of Cylinders
- 4
- Engine Stroke
- 4-stroke
- Valves
- 16
- Valves Per Cylinder
- 4
- Valve Configuration
- DOHC
- Cooling System
- Liquid-cooled
- Engine Oil
- 10W-40 SAE - 3,9 L
- Lubrication
- Wet Sump
- Induction
- Supercharged
- Spark Plug
- NGK IFR9E-G
- Starting
- Electric
- Gear Ratio per Gear
-
1st - 3.188 (51/16)
2nd - 2.526 (48/19)
3rd - 2.045 (45/22)
4th - 1.727 (38/22)
5th - 1.524 (32/21)
6th - 1.348 (31/23)
- Displacement
- 998 cc
- Bore X Stroke
- 76 mm × 55 mm
- Compression Ratio
- 8.5 : 1
- Horsepower
- 200 PS (147 kW) / 210 PS (154.5 kW) with Ram Air
- Torque
- 133.5 Nm / 10,500 rpm
- Fuel System
- Injection
- Fuel Type
- Petrol
Transmission
- Transmission Type
- Manual
- Number Of Speeds
- 6-speed
- Clutch
- Wet Multi-Plate
- Primary Drive Ratio
- 1.551 (76/49)
- Final Drive Ratio
- 2.444 (44/18)
- Reverse
- No
Chassis
- Frame
- Trellis, high-tensile steel with Swingarm Mounting Plate
- Rake (fork angle)
- 24.4°
- Trail
- 103 mm / 4.06 in
- Front Suspension Type
- KYB AOS-II inverted 43 mm fork, fully adjustable
- Front Wheel Travel
- 120 mm / 4.72 in
- Rear Suspension Type
- KYB monoshock, fully adjustable
- Rear Wheel Travel
- 135 mm / 5.31 in
Dimension
- Overall Length
- 2085 mm / 82.09 in
- Overall Width
- 770 mm / 30.31 in
- Seat Height
- 825 mm / 32.48 in
- Seat Type
- Single
- Wheelbase
- 1455 mm / 57.28 in
- Ground Clearance
- 130 mm / 5.12 in
- Dry Weight
- 216 kg / 476.20 lb
- Wet Weight
- 238 kg / 524.70 lb
- Fuel Capacity
- 17 l / 4.49 gal
- Overall Heigth
- 1125 mm / 44.29 in
Brakes and tyres
- Front Brake Type
- Dual Disc
- Rear Brake Type
- Single Disc
- Front Brake Diameter
- 330 mm / 12.99 in
- Rear Brake Diameter
- 250 mm / 9.84 in
- Tube / Tubeless
- Tubeless
- Wheel Type
- Cast Aluminium
- Front Wheel
- 17"
- Rear Wheel
- 17"
- Front Tire Size
- 120/70 ZR17 (M/C)
- Rear Tire Size
- 200/55 ZR17 (M/C)
Instrument console features
- Speedometer
- Digital
- Tachometer
- Analogue
- Fuel Gauge
- Digital bar-type
Battery and lighting
- Pass Light
- Yes
- Battery Type
- Maintenance-free lithium or lead-acid
- Battery Voltage
- 12 V / 8.6 Ah
- Headlight Type
- LED (single projector)
- Turn Signals Type
- LED
Comfort features
- Electric Start
- Yes
- Pillion Footrest
- No
- Step-up Seat / Split Seat
- No
- ABS available
- Yes
- Top Speed
- 337 km/h / 209 mph
Colors
Mirror Coated Spark Black
