Honda VTX 1300 - Black Betty

Honda VTX 1300 - Black Betty

Nothing

Went to go on a ride at 9am this morning. put the key in Betty, and nothing no light no nothing. I've checked every fuse on the bike. still nothing I even checked the battery ( Fully charged). I am dumb founded. I'm even called the bike shop. they told me to do everything I already checked. Is there a fuse or fuses that are hidden some where. 2004 Honda Vtx 1300s. I really need advice on this.

Honda VTX 1300 Cruisers Assist Assist Honda Assist VTX 1300 Assist Cruisers

2

14

Follow 2.1K

Comments

JoeRider 13 Aug 2021

if all the fuses test as ok, then maybe try removing each fuse one at a time, if something is causing a short then isolating it and observing a different result to nothing at all happening might give you some more questions at least to work with.

1
Reply
- Barry 13 Aug 2021 author

  JoeRider, yeah maybe, my next door neighbor said something about that but said test each circuit that the fuse goes into. I've done almost everything, except take the bike apart. let me try it your way to see what results I get. I will post something in a few here with what I find.

  1
  Reply
Barry 13 Aug 2021 author

Thanks. JoeRider.

1
Reply
- JoeRider 13 Aug 2021

  Barry, I'm no mechanic but if I can offer any useful advice ? no power at all, could also be a simple issue - have had same from a faulty kill switch (after being totally stumped by a no power problem)

  1
  Reply
JoeRider 13 Aug 2021

some good advice for the VTX here https://www.vtxoa.com/threads/no-electricity-on-2004-honda-vtx-1300c.326061/#post-3505512

apparently should also be a 30amp main fuse near the starter relay - some other good troubleshooting tips there, good luck with it! hopefully a quick fix

1
Reply
Barry 13 Aug 2021 author

I found a Fuse 30 amp. under the left side panel.. Wow really.. in the most odd place

1
Reply
Barry 13 Aug 2021 author

you really can't see it but it's the little box.

1
Reply
Barry 13 Aug 2021 author

it starts right up now. he'll yes..

1
Reply
- JoeRider 16 Aug 2021

  Barry, Hell yeh! haha, they couldn't have hidden it any better

  0
  Reply
Barry 13 Aug 2021 author

Thanks a million JoeRider..

1
Reply
- JoeRider 16 Aug 2021

  Barry, happy to assist ⚡small wins like not having to take bike to a mechanic are priceless - happy you're back on road ?

  0
  Reply
Mr. Daddy 17 Aug 2021

I had a Shadow and they seemed to have a common issue with the ignition switch. Maybe a similar issue with the VTX?

1
Reply
- Barry 17 Aug 2021 author

  Mr. Daddy, I had checked everything done every test known to man. Even Called the Honda Dealer. Everyone was stumped. So I posted my issue here. So yesterday I did a fuse check again. And again all fuses checked out good. So I turned to YouTube, And I found out there is one fuse hidden from humans. Youtube showed me where it was. 30 amp fuse pulled it out and sur enough it was blown. replaced it and BAM. The Betty started right up. so now I'm just waiting for the rain to stop so I can Ride.

  0
  Reply
Barry 20 Aug 2021 author

ok I figured out why it kept blowing fuses. I had a wire from my radio that had been smashed and was touching metal. I fixed that and now it's doing good.

1
Reply
