Featuring long-travel suspension, a front disc brake and tough motocross-style bodywork, the rugged TT-R125 is the ideal bike for youth and adult riders – who want an enjoyable and easy to maintain fun bike that can handle any terrain.

Fun for one, fun for all.

At the heart of this durable off roader there’s a compact air-cooled 125cc 4-stroke engine delivering plenty of smooth and controllable power. An electric starter makes it easy to get moving, and the 5-speed gearbox allows you to get maximum enjoyment from the TT-R125 – wherever you may go.

The exiting specification also includes long-travel front and rear suspension for smooth and confident handling – as well as a 220mm front disc brake, impact-resistant polypropylene bodywork and a 19-inch front wheel and 16-inch rear wheel with knobbly tyres. Let the fun begin!

Designed for older kids who may be graduating from the mid-sized TT-R110 – as well as for adults who want a light and easy to maintain fun bike – the TT-R125 is the most powerful bike in the TT-R line-up.

2023 Yamaha TT-R125 - USA Specifications/Technical Details

Key Features

• Top-of-the-range 125cc 4-stroke off-road fun bike
• Long-travel front and rear suspension
• Powerful front and rear brakes

ENGINE

• Torque-Rich Engine
  Potent 124cc air-cooled SOHC four-stroke powerplant puts out torquey, broad power tuned for off-road performance in a wide range of trail conditions.
• Responsive Power
  Crisp, dependable throttle response from the 20mm Mikuni® carburetor.
• Five-Speed Transmission
  Smooth-shifting, five-speed transmission with heavy-duty clutch is geared for maximum versatility and usable power delivery.
• Digital Ignition
  CDI ignition system is ultra-reliable and never needs maintenance.
• Low Maintenance Engine
  Automatic cam chain tensioner means minimal maintenance and longer engine life.
• Easy Serviceability
  Easy-access, tool-free air filter adds extra convenience during maintenance.
• Forest-Friendly Exhaust
  The lightweight exhaust system features quiet, USFS-approved spark arrestor.

CHASSIS/SUSPENSION

• Robust, Compact Frame
  Rigid frame design features a long wheelbase to accommodate bigger riders while maintaining quick, agile off-road handling.
• Trail-Ready Front Fork
  A 31mm telescopic front fork with 7.1 inches of travel has preload adjustability for plush, confidence-inspiring control over rough terrain.
• Advanced Rear Suspension
  The single rear shock features compression and the rebound damping adjustability with 6.6 inches of travel for predictable handling and control.
• Nimble Wheels and Tires
  Big 19-inch front and 16-inch rear wheels on the 125 offer great handling and all-terrain ability with sharp, predictable steering.
• Lightweight Swingarm
  The TT-R125 features a lightweight aluminum box-section swingarm with snail-type chain adjusters for reduced unsprung weight and optimum suspension performance.
• Powerful Braking
  Front rotor and rear drum brakes deliver strong, dependable stopping power.
• Durable Knobby Tires
  Knobby tires offer superb grip and exceptional wear.

ADDITIONAL FEATURES

• Low Seat Height
  The long, YZ-style seat is low and comfortable and allows easy rider movement with a gripper-style to aid in seat-of-the-pants feel.
• Racing Style
  Team Yamaha-inspired colors and graphics with front and side number plates are styled like the YZ motocross lineup, while the sleek, narrow fuel tank creates a big-bike look and feel.
• Grippy Foot Pegs
  Large folding, cleated foot pegs provide excellent footing, even in wet or muddy conditions.
• Fork Protection
  Durable fork boots ensure excellent fork seal and stanchion tube protection.

2023 Yamaha TT-R125 –&& European Specifications/Technical Details

Engine

• Engine type Single cylinder;4-stroke;Air-cooled;2-valves;SOHC
• Displacement 124cc
• Bore x stroke 54.0 x 54.0 mm
• Compression ratio 10.0 : 1
• Lubrication system Wet sump
• Clutch type Wet;Multiple Disc
• Ignition system CDI
• Starter system Electric and kick
• Transmission system Constant Mesh;5-speed
• Final transmission Chain
• Fuel system Mikuni VM20/1

Chassis

• Frame Diamond
• Caster angle 28º30
• Trail 107 mm
• Front suspension system Telescopic fork
• Rear suspension system Swingarm;link suspension
• Front travel 180 mm
• Rear travel 168 mm
• Front brake Hydraulic Disk, Ø220 mm
• Rear brake Mechanical leading trailing drum brake, Ø110 mm
• Front tyre 70/100-19 42M
• Rear tyre 90/100-16 52M

Dimensions

• Overall length 1,885 mm
• Overall width 795 mm
• Overall height 1,085 mm
• Seat height 805 mm
• Wheel base 1,270 mm
• Minimum ground clearance 295 mm
• Wet weight (including full oil and fuel tank) 90 kg
• Fuel tank capacity 6.0 litres
• Oil tank capacity 1.2 litres
